This specification describes a mechanism to protect optical barcodes, such as those found on driver's licenses (PDF417) and travel documents (MRZ), using Verifiable Credentials [[VC-DATA-MODEL-2.0]]. The Verifiable Credential representations are compact enough such that they fit in under 150 bytes and can thus be integrated with traditional two-dimensional barcodes that are printed on physical cards using standard printing processes.

This specification is experimental.

Introduction

Physical credentials, such as driver's licenses, passports, and travel credentials often include machine-readable data that can be used to quickly read the information from the document. This information is encoded in formats such as PDF417 [[ISO15438-2015]], machine-readable zone (MRZ) [[ICAO9303-3]], and other optically scannable codes that are formatted in one-dimensional or two-dimensional "bars"; thus the term "barcode". This information is often not protected from tampering and the readily available barcode generation and scanning libraries mean that it is fairly trivial for anyone to generate these barcodes.

It is, therefore, useful for an issuer of these barcodes to protect the information contained within the barcode as well as the entity that generated the barcode.

The [[[VC-DATA-MODEL-2.0]]] specification provides a global standard for expressing credential information, such as those in a driver's license or travel document. The [[[VC-DATA-INTEGRITY]]] specification provides a global standard for securing credential information. These two specifications, when combined, provide a means of protecting credentials from tampering, expressing authorship of the credential, and providing the current status of a credential in a privacy-protecting manner. These data formats, however, tend to be too large to express in an optical barcode.

The [[[CBOR-LD]]] specification provides a means of compressing secured verifiable credentials to the point at which it becomes feasible to express the information as an optical barcode, or embedded within an optical barcode.

This specification describes a mechanism to protect optical barcodes, such as those found on driver's licenses (PDF417) and travel documents (MRZ), by using a verifiable credential [[VC-DATA-MODEL-2.0]] to express information about the barcode, which is then secured using Data Integrity [[VC-DATA-INTEGRITY]], and then compressed using CBOR-LD [[CBOR-LD]]. The resulting verifiable credential representations are compact enough such that they fit in under 140 bytes and can thus be integrated with traditional two-dimensional barcodes that are printed on physical cards using standard printing processes. This adds tamper resistance to the barcode while optionally enhancing the barcode to provide information related to whether or not the physical document has been revoked or suspended by the issuer.

Driver's License Example

This section provides an example on how the technology in this specification can be utilized to secure the optical barcode on a driver's license that uses a PDF417 barcode. We start off with an example driver's license:

Picture of the front of a driver's license issued by the state of Utopia which contains a picture of the individual that is the subject of the driver's license along with their attributes, such as name, address, height, weight, eye color, and driving privileges.
The front of a driver's license issued by the state of Utopia.

The back of the driver's license contains a PDF417 barcode:

Picture of the back of a driver's license issued by the state of Utopia, containing usage rules as well as a PDF417 barcode that encodes much of the information displayed on the front of the card.
A back of a driver's license issued by the state of Utopia.

The PDF417 data contains information that is secured using the algorithms described in this specification. Namely, the PDF417 barcode contains a verifiable credential of the following form.

{
  "@context": [
    "https://www.w3.org/ns/credentials/v2",
    "https://w3id.org/vdl/v2",
    "https://w3id.org/vdl/utopia/v1"
  ],
  "type": [
    "VerifiableCredential",
    "OpticalBarcodeCredential"
  ],
  // the issuer value below is defined as a URL in the 'utopia/v1' context above
  "issuer": "did:web:dmv.utopia.example",
  "credentialStatus": {
    "type": "TerseBitstringStatusListEntry",
    "terseStatusListBaseUrl": "https://dmv.utopia.gov/statuses/12345/status-lists"
    "terseStatusListIndex": 123567890
  },
  "credentialSubject": {
    "type": "AamvaDriversLicenseScannableInformation",
    "protectedComponentIndex": "uP_BA"
  },
  "proof": {
    "type": "DataIntegrity",
    "cryptosuite": "ecdsa-xi-2023",
    // the public key below is defined as a URL in the 'utopia/v1' context above
    "verificationMethod": "did:web:dmv.utopia.example#key-1",
    "proofPurpose": "assertionMethod",
    "proofValue": "z4peo48uwK2EF4Fta8P...HzQMDYJ34r9gL"
  }
}


The verifiable credential above is then compressed using [[CBOR-LD]] to the following output (in CBOR Diagnostic Notation):

1281{
  1 => [ 32768, 32769, 32770],                           // @context
  155 => [ 116, 164 ],                                   // type
  192 => 174,                                            // issuer
  186 => { 154 => 166, 206 => 178, 208 => 1234567890 },  // credentialStatus
  188 => { 154 => 172, 180 => h'753FF040 },              // credentialSubject
  194 => {                                               // proof
    154 => 108,                                          // type
    214 => 4,                                            // cryptosuite
    224 => 230                                           // verificationMethod
    228 => 176,                                          // proofPurpose
    210 => Uint8Array(65) [ ... ],                       // proofValue
  }
}


Employment Authorization Example

This section provides an example on how the technology in this specification can be utilized to secure the machine-readable zone on an employment authorization document that uses a machine-readable zone (MRZ) on the back of the card. We start off with an example employment authorization document:

Picture of the front of an employment authorization document issued by the state of Utopia which contains a picture of the individual that is the subject of the document along with their attributes, such as name, address, height, weight, eye color, and employment privileges.
The front of an employment authorization document issued by the state of Utopia.

The back of the employment authorization document contains a machine-readable zone (MRZ) containing information designed to be read through optical character recognition:

Picture of the back of a employment authorization document issued by the state of Utopia, containing usage rules as well as machine-readable zone data that encodes much of the information displayed on the front of the card.
A back of an employment authorization document issued by the state of Utopia.

The MRZ data contains information that is secured using the algorithms described in this specification. Namely, the QR Code on the front of the card contains a verifiable credential of the following form, which secures the information on the back of the card.

{
  "@context": [
    "https://www.w3.org/ns/credentials/v2",
    "https://w3id.org/citizenship/v2",
    "https://w3id.org/citizenship/utopia/v1"
  ],
  "type": [
    "VerifiableCredential",
    "OpticalBarcodeCredential"
  ],
  // the value below is defined as a URL in the 'utopia/v1' context above
  "issuer": "did:web:immigration.utopia.example",
  "credentialSubject": {
    "type": "MachineReadableZone",
  },
  "proof": {
    "type": "DataIntegrity",
    "cryptosuite": "ecdsa-xi-2023",
    // the value below is defined as a URL in the 'utopia/v1' context above
    "verificationMethod": "did:web:immigration.utopia.example#key-4"
    "proofPurpose": "assertionMethod",
    "proofValue": "z4peo48uwK2EF4Fta8P...HzQMDYJ34r9gL"
  }
}


Readers might note that the credential above does not contain the optional `credentialStatus` property. Not every optical barcode credential issuer will have the requirement to have revocable optical barcode credentials.

The verifiable credential above is then compressed using [[CBOR-LD]] to the following output (in CBOR Diagnostic Notation):

{
  1 => [ 32768, 32769, 32770],           // @context
  155 => [ 116, 176 ],                   // type
  208 => 194,                          // issuer
  204 => { 154 => 192 },                 // credentialSubject
  210 => {                               // proof
    154 => 108,                          // type
    226 => 4,                        // cryptosuite
    236 => 242                         // verificationMethod
    240 => 196,                          // proofPurpose
    210 => Uint8Array(65) [ ... ],       // proofValue
  }
}


Terminology

Terms defined by cited specifications

Unicode code point order
This refers to determining the order of two Unicode strings (`A` and `B`), using Unicode Codepoint Collation, as defined in [[XPATH-FUNCTIONS]], which defines a total ordering of strings comparing code points. Note that for UTF-8 encoded strings, comparing the byte sequences gives the same result as code point order.

A conforming document is any concrete expression of the data model that complies with the normative statements in this specification. Specifically, all relevant normative statements in Sections and of this document MUST be enforced.

A conforming processor is any algorithm realized as software and/or hardware that generates or consumes a conforming document. Conforming processors MUST produce errors when non-conforming documents are consumed.

This document contains examples of JSON and JSON-LD data. Some of these examples are invalid JSON, as they include features such as inline comments (`//`) explaining certain portions and ellipses (`...`) indicating the omission of information that is irrelevant to the example. Such parts need to be removed if implementers want to treat the examples as valid JSON or JSON-LD.

Design Goals

The following are the design goals of the technology in this specification:

Data Model

The following sections outline the data model that is used by this specification to express [=verifiable credentials=] that secure optically printed information such as barcodes and machine-readable zones on travel documents.

OpticalBarcodeCredential

An `OpticalBarcodeCredential` is used to secure the contents of an optical barcode in a way that provides 1) authorship information , 2) tamper resistance, and 3) optionally, revocation and suspension status. In other words, the credential can tell you who issued the optical barcode, if the optical barcode has been tampered with since it was first issued, and whether or not the issuer of the optical barcode still warrants that the document is still valid or not. These features provide significant anti-fraud protections for physical documents.

The `credentialSubject` of an `OpticalBarcodeCredential` is either of type `AamvaDriversLicenseScannableInformation` or a `MachineReadableZone`. A `AamvaDriversLicenseScannableInformation` signifies that the verifiable credential secures the PDF417 barcode on the physical document as well as the information expressed in the verifiable credential. A `MachineReadableZone` signifies that the verifiable credential secures the machine-readable zone on the physical document as well as the information expressed in the verifiable credential.

If an `OpticalBarcodeCredential` is of type `AamvaDriversLicenseScannableInformation`, there is a REQUIRED additional field `protectedComponentIndex` that contains information about which fields in the PDF417 are digitally signed. `protectedComponentIndex` MUST be a three byte/24 bit value that is multibase-base64url encoded for a total of 5 characters in the JSON-LD credential. There are 22 mandatory fields in an AAMVA compliant driver's license PDF417 [[aamva-dl-id-card-design-standard]], and the first 22 bits of the `protectedComponentIndex` value correspond to these fields. Each AAMVA mandatory field begins with a three character element ID (e.g. `DBA` for document expiration date). To construct a mapping between bits in the `protectedComponentIndex` value and these fields, sort these element IDs according to Unicode code point order. Then, if a bit in position `i` of `protectedComponentIndex` is `1`, the AAMVA mandatory field in position `i` of the sorted element IDs is protected by the digital signature. The last two bits in `protectedComponentIndex` MUST be `0`. For more information, see Section [[[#create-opticaldatabytes]]].

In order to achieve as much compression as possible, it is RECOMMENDED that the `issuer` and `verificationMethod` fields utilize terms from a JSON-LD Context, which can then be compressed down to a few bytes due to CBOR-LD's semantic compression mechanism.

An example of an optical barcode credential that utilizes the properties specified in this section is provided below:

{
  "@context": [
    "https://www.w3.org/ns/credentials/v2",
    "https://w3id.org/vdl/v2",
    "https://w3id.org/vdl/utopia/v1"
  ],
  "type": [
    "VerifiableCredential",
    "OpticalBarcodeCredential"
  ],
  "issuer": "did:web:dmv.utopia.example",
  "credentialStatus": {
    "type": "TerseBitstringStatusListEntry",
    "terseStatusListBaseUrl": "dmv.utopia.gov/statuses/12345/status-lists"
    "terseStatusListIndex": 123567890
  },
  "credentialSubject": {
    "type": "AamvaDriversLicenseScannableInformation",
    "protectedComponentIndex": "uP_BA"
  }
}


TerseBitstringStatusListEntry

A `TerseBitstringStatusListEntry` is a compact representation of a `BitstringStatusListEntry` as defined in the [[[VC-BITSTRING-STATUS-LIST]]] specification.

An object of type `TerseBitstringStatusListEntry` MUST have two additional properties:

To process a `TerseBitstringStatusListEntry`, apply the algorithm in Section [[[#convert-status-list-entries]]] to convert it to a `BitstringStatusListEntry`, then process it as in [[[VC-BITSTRING-STATUS-LIST]]].

Implementers need to set a value |listLength| for the length of an individual status list. This then yields a number of status lists |listCount| = 2^32 / |listLength| for a 32-bit `terseStatusListIndex`. |listLength| is needed to convert from a `TerseBitstringStatusListEntry` to a `BitstringStatusListEntry`. Noting that some values of |listLength| will harm the privacy-preserving properties of these status lists, implementations MUST use |listLength| = 2^17 and |listCount| = 2^15.

Encoding to and from barcodes

While the credentials in this specification use CBOR-LD to efficiently encode [=verifiable credentials=] in a binary format, binary data is often inefficient or incompatible to turn into standard barcode image formats directly. To that end, we provide requirements here for implementations.

It is RECOMMENDED that implementers character-encode CBOR-LD encoded `AamvaDriversLicenseScannableInformation` credentials as base64url before encoding them in a PDF417.

It is REQUIRED that implementers re-encode CBOR-LD encoded `MachineReadableZone` credentials as base45-multibase with the string 'VC1-' prepended before encoding them in a QR code.

Algorithms

The following section describes algorithms for adding and verifying digital proofs that protect optical information, such as barcodes and machine-readable zones, on physical media, such as driver's licenses and travel documents.

Generally speaking, the algorithms in this section are effectively the same as the ones in the [[[VC-DI-ECDSA]]] [[VC-DI-ECDSA]] except that the algorithm name is different because the cryptographic hashing process includes the machine-readable barcode information when calculating the digital signature such that the optical barcode is protected.

CBOR-LD Compression

This specification requires that an application-specific compression table is provided to a CBOR-LD processor when encoding and decoding verifiable credentials of type `OpticalBarcodeCredential`. A registry for all context URLs for various issuers is provided as a comma-separated value file and can be updated and modified via change requests to the file on an append-only and first-come-first-served basis. Implementations SHOULD retrieve and utilize the latest file on a monthly basis to ensure that compression and decompression supports the latest values.

Credential Creation

  1. Set |opticalData| to the data in the optical barcode to be secured.
  2. Set |statusListEntryVerbose| to the `BitstringStatusListCredential` (as defined in the [[[VC-BITSTRING-STATUS-LIST]]] specification) that the issuer wishes to add to the `OpticalBarcodeCredential`.
  3. Let |statusListEntryTerse| be an empty [=map=]. Set |statusListEntryTerse|.|type| to `TerseBitstringStatusListEntry` and |statusListEntryTerse|.|index| to the integer representation of |statusListEntryVerbose|.|statusListIndex|.
  4. Set |issuerUrl| to the URL the issuer wishes to use for credential verification.
  5. Set |unsignedStatus| to an `OpticalBarcodeCredential` with |unsignedStatus|.|issuer| set to |issuerUrl| and |unsignedStatus|.|credentialStatus| set to |statusListEntryTerse|.
  6. Set |signedStatusVc| to the result of using the algorithm in to sign |opticalData| and |unsignedStatus|.
  7. Encode |signedStatusVc| using CBOR-LD [[CBOR-LD]] and add it to the designated area of the |opticalData|.
  8. Generate the machine-readable credential (MRZ or PDF417).

Credential Validation

  1. Set |securedDocument| to the data in the PDF417 or MRZ.
  2. Set |verificationResult| to the result of applying the algorithm in Section [[[#verify-proof-ecdsa-xi-2023]]]to |securedDocument|.
  3. Set |credential| to the `OpticalBarcodeCredential` in |securedDocument|.
  4. Set |statusListEntry| to the result of applying the algorithm in Section [[[#convert-status-list-entries]]] to |credential|.
  5. Set |statusResult| to the result of applying the algorithm in Bitstring Status List v1.0: Validate Algorithm to |statusListEntry|.
  6. Return (|validationResult|, |statusResult|).

Convert Status List Entries

The algorithm in this section is used to convert the `TerseBitstringStatusListEntry` to a `BitstringStatusListEntry`, which is used after verification has been performed on the verifiable credential, during the validation process.

After verifiable credential verification has been performed, the algorithm takes an `OpticalBarcodeCredential` verifiable credential ([=struct=] |vc|), an integer |listLength| containing the number of entries in the `BitstringStatusListCredential` associated with |vc|, and a string |statusPurpose| (e.g. 'revocation', 'suspension'...) as input and returns a 'BitstringStatusListEntry' object.

  1. Set |result| to be an empty [=map=].
  2. Set |listIndex| to |vc|.|credentialStatus|.|terseStatusListIndex|/|listLength| rounded down to the next lowest integer (i.e. apply the `floor()` operation).
  3. Set |statusListIndex| to |vc|.|credentialStatus|.|terseStatusListIndex| % |listLength|.
  4. Set |result|.|statusListCredential| to the concatenation of the following values: |vc|.|credentialStatus|.|terseStatusListBaseUrl|, '/', |statusPurpose|, '/', |listIndex|.
  5. Set |result|.|type| to 'BitstringStatusListEntry'.
  6. Set |result|.|statusListIndex| to |statusListIndex|.
  7. Set |result|.|statusPurpose| to |statusPurpose|.
  8. Return |result|.

|result| can be used as input to the validation algorithm in the [[[VC-BITSTRING-STATUS-LIST]]] specification.

Implementers are advised that not all issuers will publish status list information for their verifiable credentials. Some issuers might require authorization before allowing a verifier to access a status list credential.

ecdsa-xi-2023

The `ecdsa-xi-2023` is effectively the `ecdsa-rdfc-2019` algorithm [[VC-DI-ECDSA]] with an added step that takes some "extra information" (xi) as input, such as the original optical barcode data, and includes that data in the information that is protected by the digital signature. The algorithms in this section detail how such a signature is created and verified.

Add Proof (ecdsa-xi-2023)

To generate a proof, the algorithm in Section 4.1: Add Proof in the Data Integrity [[VC-DATA-INTEGRITY]] specification MUST be executed. For that algorithm, the cryptographic suite specific transformation algorithm is defined in the Transformation (ecdsa-rdfc-2019) section of the [[[VC-DI-ECDSA]]], the hashing algorithm is defined in Section , and the proof serialization algorithm is defined in the Proof Serialization (ecdsa-rdfc-2019) section of the [[[VC-DI-ECDSA]]].

Verify Proof (ecdsa-xi-2023)

To verify a proof, the algorithm in Section 4.2: Verify Proof in the Data Integrity [[VC-DATA-INTEGRITY]] specification MUST be executed. For that algorithm, the cryptographic suite specific transformation algorithm is defined in the Transformation (ecdsa-rdfc-2019) section of the [[[VC-DI-ECDSA]]], the hashing algorithm is defined in Section , and the proof verification algorithm is defined in the Proof Verification (ecdsa-rdfc-2019) section of the [[[VC-DI-ECDSA]]].

Hashing (ecdsa-xi-2023)

The hashing algorithm is what is defined in the Hashing (ecdsa-rdfc-2019) section of the [[[VC-DI-ECDSA]]] specification with the addition of the hashing of the optical data, as described below. It is presumed that the implementation makes the machine-readable optical data (PDF417 or MRZ data) available to this hashing algorithm.

The required inputs to this algorithm are a transformed data document (transformedDocument), a canonical proof configuration (canonicalProofConfig), and the optical data (opticalDataBytes). A single hash data value represented as series of bytes is produced as output.

The hashing algorithm is what is defined in the Hashing (ecdsa-rdfc-2019) section of the [[[VC-DI-ECDSA]]] with step 3 replaced with the following two steps:

  1. Let opticalDataHash be the result of applying the same hash algorithm that was applied to hashData to the opticalDataBytes value.
  2. Let hashData be the result of joining proofConfigHash (the first hash), transformedDocumentHash (the second hash), and opticalDataHash (the third hash).

Create opticalDataBytes

`AamvaDriversLicenseScannableInformation` Credentials
  1. Set |dataToCanonicalize| to an empty array.
  2. Set |bitfieldDecoded| to be first 22 bits of the length 24 bitstring resulting from decoding `credentialSubject.protectedComponentIndex` from multibase-base64url to binary.
  3. Set |fieldsAlphabetized| to be an array containing the 22 AAMVA mandatory PDF417 Element IDs [[aamva-dl-id-card-design-standard]] sorted in Unicode code point order (i.e. ['DAC', 'DAD' ... 'DDG']).
  4. For each bit with value `1` in |bitfieldDecoded|:
    1. Set the string |fieldName| to |fieldsAlphabetized|[|i|], where |i| is the index of the bit in |bitfieldDecoded|.
    2. Set the string |fieldData| to the data that will be in the PDF417 associated with that field name.
    3. Concatenate |fieldData| to the end of |fieldName|, concatenate a newline character (`\n`, `U+000A`) to the end, and append the result to |dataToCanonicalize|.
  5. Set |canonicalizedData| to the result of sorting |dataToCanonicalize| in Unicode code point order and then applying a join operation to create a single string from the array.
  6. Hash |canonicalizedData| and return the result.
`MachineReadableZone` Credentials
  1. Set |dataToCanonicalize| to an empty array.
  2. For each line in the Machine Readable Zone on the credential:
    1. Set |mrzLine| to a string containing the data in that line.
    2. Append a newline character to the end of |mrzLine| and append |mrzLine| to |dataToCanonicalize|.
  3. Set |canonicalizedData| to the result of ordering the elements of |dataToCanonicalize| to match the order they appear on the credential and then applying a join operation to create a single string from the array.
  4. Hash |canonicalizedData| and return the result.

Proof Configuration (ecdsa-xi-2023)

The proof configuration algorithm is what is defined in the Proof Configuration (ecdsa-rdfc-2019) section of the [[[VC-DI-ECDSA]]] with step 4 replaced with the following step:

  1. If options.type is not set to `DataIntegrityProof` and proofConfig.cryptosuite is not set to `ecdsa-xi-2023`, an `INVALID_PROOF_CONFIGURATION` error MUST be raised.

Security Considerations

Before reading this section, readers are urged to familiarize themselves with general security advice provided in the Security Considerations section of the Data Integrity specification as well as the specific security advice provided in the Security Considerations section of the ECDSA Cryptosuites specification.

In the following sections, we review these important points and direct the reader to additional information.

Optical Data Duplication

One attack vector against `OpticalBarcodeCredentials` involves duplicating an optical barcode containing a digital signature for use on a fraudulent document. While a duplicated barcode will pass signature validation like the original, this attack is mitigated by the document verifier checking the following three things: the signed data matches the data visible on the document, the signed data matches the physical attributes of the user, and the visible data matches the physical attributes of the user. When these three are all equivalent, the only way the `OpticalBarcodeCredential` could be a duplicate is if the fraudulent document creator had access to a real `OpticalBarcodeCredential` where the signed physical attributes fully overlapped with those of the user of the fraudulent document. The low likelihood of an undetected stolen `OpticalBarcodeCredential` existing that completely matches the appearance of an arbitrary person makes this attack unlikely to succeed.

Partially Signed Optical Data

It is possible that in some cases the digital signature cannot be created over the entirety of the existing optical data. For example, consider a case where a serial number is injected by a physical credential manufacturer such that it is not known to the issuer at signature time. In this case, the verifier will assume that any data not digitally signed could have been changed in the optical barcode without impacting the `OpticalBarcodeCredential's` ability to successfully validate.

When checking that data from the optical barcode matches the data visible on the document as well as the characteristics of the document holder, implementers are advised to only use the fields that are digitally signed. [=Verifiers=] are advised to only use fields protected by the digital signature, no matter how commonly the other fields are used for fraud detection on unsigned documents. For example, if eye color and hair color are protected by the signature, but the [=holder=]'s portrait is not, [=verifiers=] are advised to emphasize the eye color and hair color when attempting to detect fraud over the portrait.

Implementers of software used by [=verifiers=] are advised to only display card data that has been secured via digital signature during the verification process. Displaying unsigned data, which could have been tampered with, could interfere with fraud detection.

Safe Verification

[=Verifiers=] are advised to always use trusted programs and interfaces to check the validity of the `OpticalBarcodeCredential`. Use of untrusted software to verify a document could result in a fraudulent credential being accepted, or a genuine credential being stolen.

Privacy Considerations

Before reading this section, readers are urged to familiarize themselves with general security advice provided in the Security Considerations section of the Data Integrity specification as well as the specific security advice provided in the Security Considerations section of the ECDSA Cryptosuites specification.

The following section describes privacy considerations that developers implementing this specification should be aware of in order to avoid violating privacy assumptions.

Add security considerations specific to this specification.

Test Vectors

This section contains examples of Verifiable Credential Barcodes as well as step-by-step processes for how they are generated and how they are verified.

Throughout this section we will analyze two running examples, one a VCB securing the MRZ of a Utopia Employment Authorization Document, and one a VCB securing the PDF417 of a Utopia Driver's License.

Creating VCBs

Utopia Driver's License

We start with the data that will be signed by the VCB (i.e., mandatory AAMVA fields from a PDF417):

DACJOHN
DADNONE
DAG123 MAIN ST
DAIANYVILLE
DAJUTO
DAKF87P20000
DAQF987654321
DAU069 IN
DAYBRO
DBA04192030
DBB04191988
DBC1
DBD01012024
DCAC
DCBNONE
DCDNONE
DCFUTODOCDISCRIM
DCGUTO
DCSSMITH
DDEN
DDFN
DDGN

Creating `opticalDataBytes`

Assume for simplicity that the only data in the PDF417 that you want to sign is first name (DAC), last name (DCS), and license number (DAQ). The bitstring value for use in `protectedComponentIndex` is then |100000100000000000100000|, and the value of `protectedComponentIndex` is "uggAg". Applying , we get

canonicalizedData = 'DACJOHN\nDAQ987654321\nDCSSMITH\n'
opticalDataBytes:
  [188,  38, 200, 146, 227, 213,  90, 250,
  50,  18, 126, 254,  47, 177,  91,  23,
  64, 129, 104, 223, 136,  81, 116,  67,
  136, 125, 137, 165, 117,  63, 152, 207]


We now can use this hash value with to sign the VC. Executing with a `BitstringStatusListCredential`, we get the following JSON-LD VC:

Example VC
{
  "@context": [
    "https://www.w3.org/ns/credentials/v2",
    "https://w3id.org/vc-barcodes/v1",
    "https://w3id.org/utopia/v2"
  ],
  "type": [
    "VerifiableCredential",
    "OpticalBarcodeCredential"
  ],
  "credentialSubject": {
    "type": "AamvaDriversLicenseScannableInformation",
    "protectedComponentIndex": "uggAg"
  },
  "issuer": "did:key:zDnaeWjKfs1ob9QcgasjYSPEMkwq31hmvSAWPVAgnrt1e9GKj",
  "credentialStatus": {
    "type": "TerseBitstringStatusListEntry",
    "terseStatusListBaseUrl": "https://sandbox.platform.veres.dev/statuses/z19rJ4oGrbFCqf3cNTVDHSbNd/status-lists",
    "terseStatusListIndex": 3851559041
  },
  "proof": {
    "type": "DataIntegrityProof",
    "verificationMethod": "did:key:zDnaeWjKfs1ob9QcgasjYSPEMkwq31hmvSAWPVAgnrt1e9GKj#zDnaeWjKfs1ob9QcgasjYSPEMkwq31hmvSAWPVAgnrt1e9GKj",
    "cryptosuite": "ecdsa-xi-2023",
    "proofPurpose": "assertionMethod",
    "proofValue": "z4g6G3dAZhhtPxPWgFvkiRv7krtCaeJxjokvL46fchAFCXEY3FeX2vn46MDgBaw779g1E1jswZJxxreZDCrtHg2qH"
  }
}


CBOR-LD Compression and Encoding

We can now apply CBOR-LD compression to this VC. Here we use the newest version of CBOR-LD, however at the end of the section we provide VCBs encoded using older versions of CBOR-LD for interoperability testing with CBOR-LD implementations that are not up to date.

For this specficiation, we have reserved the CBOR-LD registry entry with value 100 (i.e. these payloads will begin with tag 0x0664). The parameters to encode using CBOR-LD, which can be found in the registry in the CBOR-LD specification, are then as follows:

registryEntryId: 100
typeTable:
{
  "context":
    {
      "https://www.w3.org/ns/credentials/v2": 32768,
      "https://w3id.org/vc-barcodes/v1": 32769,
      "https://w3id.org/utopia/v2": 32770
    },

  "https://w3id.org/security#cryptosuiteString":
    {
      "ecdsa-rdfc-2019": 1,
      "ecdsa-sd-2023": 2,
      "eddsa-rdfc-2022": 3,
      "ecdsa-xi-2023": 4
    }
}


The term to ID mapping that should result from processing the contexts and assigning integer values to context terms is as follows:

Map(97) {
  '@context' => 0,
  '@type' => 2,
  '@id' => 4,
  '@value' => 6,
  '@direction' => 8,
  '@graph' => 10,
  '@included' => 12,
  '@index' => 14,
  '@json' => 16,
  '@language' => 18,
  '@list' => 20,
  '@nest' => 22,
  '@reverse' => 24,
  '@base' => 26,
  '@container' => 28,
  '@default' => 30,
  '@embed' => 32,
  '@explicit' => 34,
  '@none' => 36,
  '@omitDefault' => 38,
  '@prefix' => 40,
  '@preserve' => 42,
  '@protected' => 44,
  '@requireAll' => 46,
  '@set' => 48,
  '@version' => 50,
  '@vocab' => 52,
  '...' => 100,
  'BitstringStatusList' => 102,
  'BitstringStatusListCredential' => 104,
  'BitstringStatusListEntry' => 106,
  'DataIntegrityProof' => 108,
  'EnvelopedVerifiableCredential' => 110,
  'EnvelopedVerifiablePresentation' => 112,
  'JsonSchema' => 114,
  'JsonSchemaCredential' => 116,
  'VerifiableCredential' => 118,
  'VerifiablePresentation' => 120,
  '_sd' => 122,
  '_sd_alg' => 124,
  'aud' => 126,
  'cnf' => 128,
  'description' => 130,
  'digestMultibase' => 132,
  'digestSRI' => 134,
  'exp' => 136,
  'iat' => 138,
  'id' => 140,
  'iss' => 142,
  'jku' => 144,
  'kid' => 146,
  'mediaType' => 148,
  'name' => 150,
  'nbf' => 152,
  'sub' => 154,
  'type' => 156,
  'x5u' => 158,
  'AamvaDriversLicenseScannableInformation' => 160,
  'MachineReadableZone' => 162,
  'OpticalBarcodeCredential' => 164,
  'TerseBitstringStatusListEntry' => 166,
  'protectedComponentIndex' => 168,
  'did:key:zDnaeWjKfs1ob9QcgasjYSPEMkwq31hmvSAWPVAgnrt1e9GKj' => 170,
  'did:key:zDnaeWjKfs1ob9QcgasjYSPEMkwq31hmvSAWPVAgnrt1e9GKj#zDnaeWjKfs1ob9QcgasjYSPEMkwq31hmvSAWPVAgnrt1e9GKj' => 172,
  'did:key:zDnaeZSD9XcuULaS8qmgDUa6TMg2QjF9xABnZK42awDH3BEzj' => 174,
  'did:key:zDnaeZSD9XcuULaS8qmgDUa6TMg2QjF9xABnZK42awDH3BEzj#zDnaeZSD9XcuULaS8qmgDUa6TMg2QjF9xABnZK42awDH3BEzj' => 176,
  'https://sandbox.platform.veres.dev/statuses/z19rJ4oGrbFCqf3cNTVDHSbNd/status-lists' => 178,
  'confidenceMethod' => 180,
  'credentialSchema' => 182,
  'credentialStatus' => 184,
  'credentialSubject' => 186,
  'evidence' => 188,
  'issuer' => 190,
  'proof' => 192,
  'refreshService' => 194,
  'relatedResource' => 196,
  'renderMethod' => 198,
  'termsOfUse' => 200,
  'validFrom' => 202,
  'validUntil' => 204,
  'terseStatusListBaseUrl' => 206,
  'terseStatusListIndex' => 208,
  'challenge' => 210,
  'created' => 212,
  'cryptosuite' => 214,
  'domain' => 216,
  'expires' => 218,
  'nonce' => 220,
  'previousProof' => 222,
  'proofPurpose' => 224,
  'proofValue' => 226,
  'verificationMethod' => 228,
  'assertionMethod' => 230,
  'authentication' => 232,
  'capabilityDelegation' => 234,
  'capabilityInvocation' => 236,
  'keyAgreement' => 238
}


For more information on the above, see .

This results in the following encoded credential:

d90664a60183198000198001198002189d82187618a418b8a3189c18a618ce18b218d01ae592208118baa2189c18a018a8447582002018be18aa18c0a5189c186c18d60418e018e618e258417ab7c2e56b49e2cce62184ce26818e15a8b173164401b5d3bb93ffd6d2b5eb8f6ac0971502ae3dd49d17ec66528164034c912685b8111bc04cdc9ec13dbadd91cc18e418ac

diagnostic:
1636(
  {
    1: [32768, 32769, 32770],
    157: [118, 164],
    184: {156: 166, 206: 178, 208: 3851559041},
    186: {156: 160, 168: h'75820020'},
    190: 170,
    192: {
      156: 108,
      214: 4,
      224: 230,
      226: h'7AB7C2E56B49E2CCE62184CE26818E15A8B173164401B5D3BB93FFD6D2B5EB8F6AC0971502AE3DD49D17EC66528164034C912685B8111BC04CDC9EC13DBADD91CC',
      228: 172
    }
  }
)


Encoding the Driver's License CBORLD as base64url and inserting the result into the PDF417 bytes in the 'ZZA' field in the 'ZZ' subfile:

bytes(@\n\x1e\rANSI 000000090002DL00410234ZZ02750202DLDAQF987654321\nDCSSMITH\nDDEN\nDACJOHN\nDDFN\nDADNONE\nDDGN\nDCAC\nDCBNONE\nDCDNONE\nDBD01012024\nDBB04191988\nDBA04192030\nDBC1\nDAU069 IN\nDAYBRO\nDAG123 MAIN ST\nDAIANYVILLE\nDAJUTO\nDAKF87P20000  \nDCFUTODOCDISCRIM\nDCGUTO\nDAW158\nDCK1234567890\nDDAN\rZZZZA2QZkpgGDGYAAGYABGYACGJ2CGHYYpBi4oxicGKYYzhiyGNAa5ZIggRi6ohicGKAYqER1ggAgGL4YqhjApRicGGwY1gQY4BjmGOJYQXq3wuVrSeLM5iGEziaBjhWosXMWRAG107uT_9bSteuPasCXFQKuPdSdF-xmUoFkA0yRJoW4ERvATNyewT263ZHMGOQYrA==\r)


The above can now be turned into a barcode:

A VCB from a Utopia driver's license.
A VCB from a Utopia driver's license.

Utopia Employment Authorization Document

We start with the data that will be signed by the VCB (i.e an MRZ):

IAUTO0000007010SRC0000000701<<
8804192M2601058NOT<<<<<<<<<<<5
SMITH<<JOHN<<<<<<<<<<<<<<<<<<<

Creating `opticalDataBytes`

For the EAD, we apply :

canonicalizedData = 'IAUTO0000007010SRC0000000701<<\n8804192M2601058NOT<<<<<<<<<<
<5\nSMITH<<JOHN<<<<<<<<<<<<<<<<<<<\n'
opticalDataBytes:
[8, 198, 126, 183,  25, 160, 166, 112,
254, 184, 189,  47, 225, 211, 125, 210,
132, 137, 45,  86, 169,  28,  57, 165,
46, 253, 9, 137, 145,  42, 192, 113]


We now can use this hash value with to sign the VC. Executing without adding status, we get the following JSON-LD VC:

Example VC
{
  "@context": [
    "https://www.w3.org/ns/credentials/v2",
    "https://w3id.org/vc-barcodes/v1",
    "https://w3id.org/utopia/v2"
  ],
  "type": [
    "VerifiableCredential",
    "OpticalBarcodeCredential"
  ],
  "credentialSubject": {
    "type": "MachineReadableZone"
  },
  "issuer": "did:key:zDnaeZSD9XcuULaS8qmgDUa6TMg2QjF9xABnZK42awDH3BEzj",
  "proof": {
    "type": "DataIntegrityProof",
    "verificationMethod": "did:key:zDnaeZSD9XcuULaS8qmgDUa6TMg2QjF9xABnZK42awDH3BEzj#zDnaeZSD9XcuULaS8qmgDUa6TMg2QjF9xABnZK42awDH3BEzj",
    "cryptosuite": "ecdsa-xi-2023",
    "proofPurpose": "assertionMethod",
    "proofValue": "z4B8AQgjwgsEdcPEZkrkK2mTVKn7qufoDgDkv9Qitf9tjxQPMoJaGdXwDrThjp7LUdvzsDJ7UwYu6Xpm9fjbo6QnJ"
  }
}


CBOR-LD Compression and Encoding

We can now apply CBOR-LD compression to this VC. Here we use the newest version of CBOR-LD, however at the end of the section we provide VCBs encoded using older versions of CBOR-LD for interoperability testing with CBOR-LD implementations that are not up to date.

For this specficiation, we have reserved the CBOR-LD registry entry with value 100 (i.e. these payloads will begin with tag 0x0664). The parameters to encode using CBOR-LD, which can be found in the registry in the CBOR-LD specification, are then as follows:

registryEntryId: 100
typeTable:
{
  "context":
    {
      "https://www.w3.org/ns/credentials/v2": 32768,
      "https://w3id.org/vc-barcodes/v1": 32769,
      "https://w3id.org/utopia/v2": 32770
    },

  "https://w3id.org/security#cryptosuiteString":
    {
      "ecdsa-rdfc-2019": 1,
      "ecdsa-sd-2023": 2,
      "eddsa-rdfc-2022": 3,
      "ecdsa-xi-2023": 4
    }
}


The term to ID mapping that should result from processing the contexts and assigning integer values to context terms is as follows:

Map(95) {
  '@context' => 0,
  '@type' => 2,
  '@id' => 4,
  '@value' => 6,
  '@direction' => 8,
  '@graph' => 10,
  '@included' => 12,
  '@index' => 14,
  '@json' => 16,
  '@language' => 18,
  '@list' => 20,
  '@nest' => 22,
  '@reverse' => 24,
  '@base' => 26,
  '@container' => 28,
  '@default' => 30,
  '@embed' => 32,
  '@explicit' => 34,
  '@none' => 36,
  '@omitDefault' => 38,
  '@prefix' => 40,
  '@preserve' => 42,
  '@protected' => 44,
  '@requireAll' => 46,
  '@set' => 48,
  '@version' => 50,
  '@vocab' => 52,
  '...' => 100,
  'BitstringStatusList' => 102,
  'BitstringStatusListCredential' => 104,
  'BitstringStatusListEntry' => 106,
  'DataIntegrityProof' => 108,
  'EnvelopedVerifiableCredential' => 110,
  'EnvelopedVerifiablePresentation' => 112,
  'JsonSchema' => 114,
  'JsonSchemaCredential' => 116,
  'VerifiableCredential' => 118,
  'VerifiablePresentation' => 120,
  '_sd' => 122,
  '_sd_alg' => 124,
  'aud' => 126,
  'cnf' => 128,
  'description' => 130,
  'digestMultibase' => 132,
  'digestSRI' => 134,
  'exp' => 136,
  'iat' => 138,
  'id' => 140,
  'iss' => 142,
  'jku' => 144,
  'kid' => 146,
  'mediaType' => 148,
  'name' => 150,
  'nbf' => 152,
  'sub' => 154,
  'type' => 156,
  'x5u' => 158,
  'AamvaDriversLicenseScannableInformation' => 160,
  'MachineReadableZone' => 162,
  'OpticalBarcodeCredential' => 164,
  'TerseBitstringStatusListEntry' => 166,
  'protectedComponentIndex' => 168,
  'did:key:zDnaeWjKfs1ob9QcgasjYSPEMkwq31hmvSAWPVAgnrt1e9GKj' => 170,
  'did:key:zDnaeWjKfs1ob9QcgasjYSPEMkwq31hmvSAWPVAgnrt1e9GKj#zDnaeWjKfs1ob9QcgasjYSPEMkwq31hmvSAWPVAgnrt1e9GKj' => 172,
  'did:key:zDnaeZSD9XcuULaS8qmgDUa6TMg2QjF9xABnZK42awDH3BEzj' => 174,
  'did:key:zDnaeZSD9XcuULaS8qmgDUa6TMg2QjF9xABnZK42awDH3BEzj#zDnaeZSD9XcuULaS8qmgDUa6TMg2QjF9xABnZK42awDH3BEzj' => 176,
  'https://sandbox.platform.veres.dev/statuses/z19rJ4oGrbFCqf3cNTVDHSbNd/status-lists' => 178,
  'confidenceMethod' => 180,
  'credentialSchema' => 182,
  'credentialStatus' => 184,
  'credentialSubject' => 186,
  'evidence' => 188,
  'issuer' => 190,
  'proof' => 192,
  'refreshService' => 194,
  'relatedResource' => 196,
  'renderMethod' => 198,
  'termsOfUse' => 200,
  'validFrom' => 202,
  'validUntil' => 204,
  'challenge' => 206,
  'created' => 208,
  'cryptosuite' => 210,
  'domain' => 212,
  'expires' => 214,
  'nonce' => 216,
  'previousProof' => 218,
  'proofPurpose' => 220,
  'proofValue' => 222,
  'verificationMethod' => 224,
  'assertionMethod' => 226,
  'authentication' => 228,
  'capabilityDelegation' => 230,
  'capabilityInvocation' => 232,
  'keyAgreement' => 234
}


For more information on the above, see .

Compression then results in the following encoded credential:

d90664a50183198000198001198002189d82187618a418baa1189c18a218be18ae18c0a5189c186c18d20418dc18e218de58417a9ec7f688f60caa8c757592250b3f6d6e18419941f186e1ed4245770e687502d51d01cd2c2295e4338178a51a35c2f044a85598e15db9aef00261bc5c95a744e718e018b0

diagnostic:
1636(
  {
    1: [32768, 32769, 32770],
    157: [118, 164],
    186: {156: 162},
    190: 174,
    192: {
      156: 108,
      210: 4,
      220: 226,
      222: h'7A9EC7F688F60CAA8C757592250B3F6D6E18419941F186E1ED4245770E687502D51D01CD2C2295E4338178A51A35C2F044A85598E15DB9AEF00261BC5C95A744E7',
      224: 176
    }
  }
)


Encoding the EAD CBORLD as base45-multibase and prepending 'VC1-':

VC1-RSJRPWCR803A3P0098G3A3-B02-J743853U53KGK0XJ6MKJ1OI0M.FO053.33963DN04$RAQS+4SMC8C3KM7VX4VAPL9%EILI:I1O$D:23%GJ0OUCPS0H8D2FB9D5G00U39.PXG49%SOGGB*K$Z6%GUSCLWEJ8%B95MOD0P NG-I:V8N63K53


The above can now be turned into a QR code:

Employment Authorization Document
A VCB from a Utopia EAD.
A VCB from a Utopia EAD.

For use with the following MRZ:

An MRZ on a Utopia Employment Authorization Document.
An MRZ on a Utopia Employment Authorization Document.

Verifying VCBs

We now apply the reverse process to verify.

Utopia Driver's License

Decoding and Decompressing

We first read the data from the PDF417:

bytes(@\n\x1e\rANSI 000000090002DL00410234ZZ02750202DLDAQF987654321\nDCSSMITH\nDDEN\nDACJOHN\nDDFN\nDADNONE\nDDGN\nDCAC\nDCBNONE\nDCDNONE\nDBD01012024\nDBB04191988\nDBA04192030\nDBC1\nDAU069 IN\nDAYBRO\nDAG123 MAIN ST\nDAIANYVILLE\nDAJUTO\nDAKF87P20000  \nDCFUTODOCDISCRIM\nDCGUTO\nDAW158\nDCK1234567890\nDDAN\rZZZZA2QZkpgGDGYAAGYABGYACGJ2CGHYYpBi4oxicGKYYzhiyGNAa5ZIggRi6ohicGKAYqER1ggAgGL4YqhjApRicGGwY1gQY4BjmGOJYQXq3wuVrSeLM5iGEziaBjhWosXMWRAG107uT_9bSteuPasCXFQKuPdSdF-xmUoFkA0yRJoW4ERvATNyewT263ZHMGOQYrA==\r)


We extract the data in field 'ZZA' in subfile 'ZZ', undoing the base encoding:

d90664a60183198000198001198002189d82187618a418b8a3189c18a618ce18b218d01ae592208118baa2189c18a018a8447582002018be18aa18c0a5189c186c18d60418e018e618e258417ab7c2e56b49e2cce62184ce26818e15a8b173164401b5d3bb93ffd6d2b5eb8f6ac0971502ae3dd49d17ec66528164034c912685b8111bc04cdc9ec13dbadd91cc18e418ac


We now decompress with CBOR-LD to get the original JSON-LD VC to be verified. Again, the parameters are associated with CBOR-LD registry entry 100.

typeTable:
{
  "context":
    {
      "https://www.w3.org/ns/credentials/v2": 32768,
      "https://w3id.org/vc-barcodes/v1": 32769,
      "https://w3id.org/utopia/v2": 32770
    },

  "https://w3id.org/security#cryptosuiteString":
    {
      "ecdsa-rdfc-2019": 1,
      "ecdsa-sd-2023": 2,
      "eddsa-rdfc-2022": 3,
      "ecdsa-xi-2023": 4
    }
}


The ID to term mapping that should result from processing the contexts and assigning integer values to context terms is as follows. Note that this is the inverse of the map constructed during compression.

Map(97) {
  0 => '@context',
  2 => '@type',
  4 => '@id',
  6 => '@value',
  8 => '@direction',
  10 => '@graph',
  12 => '@included',
  14 => '@index',
  16 => '@json',
  18 => '@language',
  20 => '@list',
  22 => '@nest',
  24 => '@reverse',
  26 => '@base',
  28 => '@container',
  30 => '@default',
  32 => '@embed',
  34 => '@explicit',
  36 => '@none',
  38 => '@omitDefault',
  40 => '@prefix',
  42 => '@preserve',
  44 => '@protected',
  46 => '@requireAll',
  48 => '@set',
  50 => '@version',
  52 => '@vocab',
  100 => '...',
  102 => 'BitstringStatusList',
  104 => 'BitstringStatusListCredential',
  106 => 'BitstringStatusListEntry',
  108 => 'DataIntegrityProof',
  110 => 'EnvelopedVerifiableCredential',
  112 => 'EnvelopedVerifiablePresentation',
  114 => 'JsonSchema',
  116 => 'JsonSchemaCredential',
  118 => 'VerifiableCredential',
  120 => 'VerifiablePresentation',
  122 => '_sd',
  124 => '_sd_alg',
  126 => 'aud',
  128 => 'cnf',
  130 => 'description',
  132 => 'digestMultibase',
  134 => 'digestSRI',
  136 => 'exp',
  138 => 'iat',
  140 => 'id',
  142 => 'iss',
  144 => 'jku',
  146 => 'kid',
  148 => 'mediaType',
  150 => 'name',
  152 => 'nbf',
  154 => 'sub',
  156 => 'type',
  158 => 'x5u',
  160 => 'AamvaDriversLicenseScannableInformation',
  162 => 'MachineReadableZone',
  164 => 'OpticalBarcodeCredential',
  166 => 'TerseBitstringStatusListEntry',
  168 => 'protectedComponentIndex',
  170 => 'did:key:zDnaeWjKfs1ob9QcgasjYSPEMkwq31hmvSAWPVAgnrt1e9GKj',
  172 => 'did:key:zDnaeWjKfs1ob9QcgasjYSPEMkwq31hmvSAWPVAgnrt1e9GKj#zDnaeWjKfs1ob9QcgasjYSPEMkwq31hmvSAWPVAgnrt1e9GKj',
  174 => 'did:key:zDnaeZSD9XcuULaS8qmgDUa6TMg2QjF9xABnZK42awDH3BEzj',
  176 => 'did:key:zDnaeZSD9XcuULaS8qmgDUa6TMg2QjF9xABnZK42awDH3BEzj#zDnaeZSD9XcuULaS8qmgDUa6TMg2QjF9xABnZK42awDH3BEzj',
  178 => 'https://sandbox.platform.veres.dev/statuses/z19rJ4oGrbFCqf3cNTVDHSbNd/status-lists',
  180 => 'confidenceMethod',
  182 => 'credentialSchema',
  184 => 'credentialStatus',
  186 => 'credentialSubject',
  188 => 'evidence',
  190 => 'issuer',
  192 => 'proof',
  194 => 'refreshService',
  196 => 'relatedResource',
  198 => 'renderMethod',
  200 => 'termsOfUse',
  202 => 'validFrom',
  204 => 'validUntil',
  206 => 'terseStatusListBaseUrl',
  208 => 'terseStatusListIndex',
  210 => 'challenge',
  212 => 'created',
  214 => 'cryptosuite',
  216 => 'domain',
  218 => 'expires',
  220 => 'nonce',
  222 => 'previousProof',
  224 => 'proofPurpose',
  226 => 'proofValue',
  228 => 'verificationMethod',
  230 => 'assertionMethod',
  232 => 'authentication',
  234 => 'capabilityDelegation',
  236 => 'capabilityInvocation',
  238 => 'keyAgreement'
}


For more information on the above, see .

Decompression then yields the following credential:

{
  "@context": [
    "https://www.w3.org/ns/credentials/v2",
    "https://w3id.org/vc-barcodes/v1",
    "https://w3id.org/utopia/v2"
  ],
  "type": [
    "VerifiableCredential",
    "OpticalBarcodeCredential"
  ],
  "credentialSubject": {
    "type": "AamvaDriversLicenseScannableInformation",
    "protectedComponentIndex": "uggAg"
  },
  "issuer": "did:key:zDnaeWjKfs1ob9QcgasjYSPEMkwq31hmvSAWPVAgnrt1e9GKj",
  "credentialStatus": {
    "type": "TerseBitstringStatusListEntry",
    "terseStatusListBaseUrl": "https://sandbox.platform.veres.dev/statuses/z19rJ4oGrbFCqf3cNTVDHSbNd/status-lists",
    "terseStatusListIndex": 3851559041
  },
  "proof": {
    "type": "DataIntegrityProof",
    "verificationMethod": "did:key:zDnaeWjKfs1ob9QcgasjYSPEMkwq31hmvSAWPVAgnrt1e9GKj#zDnaeWjKfs1ob9QcgasjYSPEMkwq31hmvSAWPVAgnrt1e9GKj",
    "cryptosuite": "ecdsa-xi-2023",
    "proofPurpose": "assertionMethod",
    "proofValue": "z4g6G3dAZhhtPxPWgFvkiRv7krtCaeJxjokvL46fchAFCXEY3FeX2vn46MDgBaw779g1E1jswZJxxreZDCrtHg2qH"
  }
}


Verifying

We apply to create the |opticalDataBytes| that `ecdsa-xi-2023` requires, using the scanned PDF417 and `protectedComponentIndex` as input.

canonicalizedData = 'DACJOHN\nDAQ987654321\nDCSSMITH\n'
opticalDataBytes:
  [188,  38, 200, 146, 227, 213,  90, 250,
  50,  18, 126, 254,  47, 177,  91,  23,
  64, 129, 104, 223, 136,  81, 116,  67,
  136, 125, 137, 165, 117,  63, 152, 207]


We then apply and to verify the credential.

Status Checking

The last step is to check the status information on the Driver's License credential. We apply to convert the `TerseBitstringStatusListEntry` into a `BitstringStatusListEntry`. Here we check two status types, 'revocation' and 'suspension', passing those strings as values of |statusPurpose|.

{
  type: 'BitstringStatusListEntry',
  statusListCredential: 'https://sandbox.platform.veres.dev/statuses/z19rJ4oGrbFCqf3cNTVDHSbNd/status-lists/revocation/29385',
  statusListIndex: 8321,
  statusPurpose: 'revocation'
}

{
  type: 'BitstringStatusListEntry',
  statusListCredential: 'https://sandbox.platform.veres.dev/statuses/z19rJ4oGrbFCqf3cNTVDHSbNd/status-lists/suspension/29385',
  statusListIndex: 8321,
  statusPurpose: 'suspension'
}


These can then be validated as in the Bitstring Status List v1.0: Validate Algorithm.

Utopia Employment Authorization Document

Decoding and Decompressing

We first read the data from the QR code:

VC1-RSJRPWCR803A3P0098G3A3-B02-J743853U53KGK0XJ6MKJ1OI0M.FO053.33963DN04$RAQS+4SMC8C3KM7VX4VAPL9%EILI:I1O$D:23%GJ0OUCPS0H8D2FB9D5G00U39.PXG49%SOGGB*K$Z6%GUSCLWEJ8%B95MOD0P NG-I:V8N63K53


We extract the data after 'VC1-' undoing the base encoding:

d90664a50183198000198001198002189d82187618a418baa1189c18a218be18ae18c0a5189c186c18d20418dc18e218de58417a9ec7f688f60caa8c757592250b3f6d6e18419941f186e1ed4245770e687502d51d01cd2c2295e4338178a51a35c2f044a85598e15db9aef00261bc5c95a744e718e018b0


We now decompress with CBOR-LD to get the original JSON-LD VC to be verified. Again, the parameters are associated with CBOR-LD registry entry 100.

typeTable:
{
  "context":
    {
      "https://www.w3.org/ns/credentials/v2": 32768,
      "https://w3id.org/vc-barcodes/v1": 32769,
      "https://w3id.org/utopia/v2": 32770
    },

  "https://w3id.org/security#cryptosuiteString":
    {
      "ecdsa-rdfc-2019": 1,
      "ecdsa-sd-2023": 2,
      "eddsa-rdfc-2022": 3,
      "ecdsa-xi-2023": 4
    }
}


The ID to term mapping that should result from processing the contexts and assigning integer values to context terms is as follows. Note that this is the inverse of the map constructed during compression.

Map(95) {
  0 => '@context',
  2 => '@type',
  4 => '@id',
  6 => '@value',
  8 => '@direction',
  10 => '@graph',
  12 => '@included',
  14 => '@index',
  16 => '@json',
  18 => '@language',
  20 => '@list',
  22 => '@nest',
  24 => '@reverse',
  26 => '@base',
  28 => '@container',
  30 => '@default',
  32 => '@embed',
  34 => '@explicit',
  36 => '@none',
  38 => '@omitDefault',
  40 => '@prefix',
  42 => '@preserve',
  44 => '@protected',
  46 => '@requireAll',
  48 => '@set',
  50 => '@version',
  52 => '@vocab',
  100 => '...',
  102 => 'BitstringStatusList',
  104 => 'BitstringStatusListCredential',
  106 => 'BitstringStatusListEntry',
  108 => 'DataIntegrityProof',
  110 => 'EnvelopedVerifiableCredential',
  112 => 'EnvelopedVerifiablePresentation',
  114 => 'JsonSchema',
  116 => 'JsonSchemaCredential',
  118 => 'VerifiableCredential',
  120 => 'VerifiablePresentation',
  122 => '_sd',
  124 => '_sd_alg',
  126 => 'aud',
  128 => 'cnf',
  130 => 'description',
  132 => 'digestMultibase',
  134 => 'digestSRI',
  136 => 'exp',
  138 => 'iat',
  140 => 'id',
  142 => 'iss',
  144 => 'jku',
  146 => 'kid',
  148 => 'mediaType',
  150 => 'name',
  152 => 'nbf',
  154 => 'sub',
  156 => 'type',
  158 => 'x5u',
  160 => 'AamvaDriversLicenseScannableInformation',
  162 => 'MachineReadableZone',
  164 => 'OpticalBarcodeCredential',
  166 => 'TerseBitstringStatusListEntry',
  168 => 'protectedComponentIndex',
  170 => 'did:key:zDnaeWjKfs1ob9QcgasjYSPEMkwq31hmvSAWPVAgnrt1e9GKj',
  172 => 'did:key:zDnaeWjKfs1ob9QcgasjYSPEMkwq31hmvSAWPVAgnrt1e9GKj#zDnaeWjKfs1ob9QcgasjYSPEMkwq31hmvSAWPVAgnrt1e9GKj',
  174 => 'did:key:zDnaeZSD9XcuULaS8qmgDUa6TMg2QjF9xABnZK42awDH3BEzj',
  176 => 'did:key:zDnaeZSD9XcuULaS8qmgDUa6TMg2QjF9xABnZK42awDH3BEzj#zDnaeZSD9XcuULaS8qmgDUa6TMg2QjF9xABnZK42awDH3BEzj',
  178 => 'https://sandbox.platform.veres.dev/statuses/z19rJ4oGrbFCqf3cNTVDHSbNd/status-lists',
  180 => 'confidenceMethod',
  182 => 'credentialSchema',
  184 => 'credentialStatus',
  186 => 'credentialSubject',
  188 => 'evidence',
  190 => 'issuer',
  192 => 'proof',
  194 => 'refreshService',
  196 => 'relatedResource',
  198 => 'renderMethod',
  200 => 'termsOfUse',
  202 => 'validFrom',
  204 => 'validUntil',
  206 => 'challenge',
  208 => 'created',
  210 => 'cryptosuite',
  212 => 'domain',
  214 => 'expires',
  216 => 'nonce',
  218 => 'previousProof',
  220 => 'proofPurpose',
  222 => 'proofValue',
  224 => 'verificationMethod',
  226 => 'assertionMethod',
  228 => 'authentication',
  230 => 'capabilityDelegation',
  232 => 'capabilityInvocation',
  234 => 'keyAgreement'
}


For more information on the above, see .

Decompression then yields the following credential:

{
  "@context": [
    "https://www.w3.org/ns/credentials/v2",
    "https://w3id.org/vc-barcodes/v1",
    "https://w3id.org/utopia/v2"
  ],
  "type": [
    "VerifiableCredential",
    "OpticalBarcodeCredential"
  ],
  "credentialSubject": {
    "type": "MachineReadableZone"
  },
  "issuer": "did:key:zDnaeZSD9XcuULaS8qmgDUa6TMg2QjF9xABnZK42awDH3BEzj",
  "proof": {
    "type": "DataIntegrityProof",
    "verificationMethod": "did:key:zDnaeZSD9XcuULaS8qmgDUa6TMg2QjF9xABnZK42awDH3BEzj#zDnaeZSD9XcuULaS8qmgDUa6TMg2QjF9xABnZK42awDH3BEzj",
    "cryptosuite": "ecdsa-xi-2023",
    "proofPurpose": "assertionMethod",
    "proofValue": "z4B8AQgjwgsEdcPEZkrkK2mTVKn7qufoDgDkv9Qitf9tjxQPMoJaGdXwDrThjp7LUdvzsDJ7UwYu6Xpm9fjbo6QnJ"
  }
}


Verifying

We apply to create the |opticalDataBytes| that `ecdsa-xi-2023` requires,using the MRZ on the EAD as input for the EAD:

canonicalizedData = 'IAUTO0000007010SRC0000000701<<\n8804192M2601058NOT<<<<<<<<<<
<5\nSMITH<<JOHN<<<<<<<<<<<<<<<<<<<\n'
opticalDataBytes:
[8, 198, 126, 183,  25, 160, 166, 112,
254, 184, 189,  47, 225, 211, 125, 210,
132, 137, 45,  86, 169,  28,  57, 165,
46, 253, 9, 137, 145,  42, 192, 113]


We then apply and to verify the credential.

Implementation Notes

CBOR-LD

When building maps from context terms to CBOR-LD integers, note that some contexts include other contexts inside of them, nested under particular types of objects. These nested contexts are called "type-scoped contexts" and they only become active when the associated type is used in the data. This is important for term ID assignment because the terms in a context are only assigned IDs once that context becomes active. In these test vectors, this is why the maps created for the Driver's License and the Employment Authorization Document are different even though the two credentials use identical contexts.

In addition, note that odd numbers are used in CBOR-LD to express terms when the associated value is plural. For example, in the CBOR-LD term to ID and id to term maps above, "type" is mapped to 156, but in places where multiple types are expressed in a VC, 157 is used instead.

Legacy CBOR-LD encoded credentials

For testing if a CBOR-LD implementation that is not fully up to date is used. The process remains the same, with the exception of the CBOR-LD decoding step, for which the following |appContextMap| should be used:
appContextMap:
[['https://www.w3.org/ns/credentials/v2', 32768],
['https://w3id.org/vc-barcodes/v1', 32769],
['https://w3id.org/utopia/v2', 32770]]


Utopia Driver's License

A VCB from a Utopia driver's license encoded with legacy CBOR-LD.
A VCB from a Utopia driver's license encoded with legacy CBOR-LD.
Utopia Employment Authorization Document
A VCB from a Utopia EAD encoded with legacy CBOR-LD.
A VCB from a Utopia EAD encoded with legacy CBOR-LD.

For use with the following MRZ:

An MRZ on a Utopia Employment Authorization Document.
An MRZ on a Utopia Employment Authorization Document.

Revision History

This section contains the substantive changes that have been made to this specification over time.

The content for this specification will be filled in after the standards-track process has been started.
